3M-B23F-VHB Black Tape

Name: 3M-B23F-VHB Black Tape
Brand: Lyncotek Venture Pvt Ltd
Price: 700.0 INR
Availability: InStock

Price 700.0 INR/ Roll

Get a Price/Quote

MOQ : 1 Roll

3M-B23F-VHB Black Tape Specification

Installation Type
Peel and Stick

Usage
Permanent Fixation, Gap Filling

Machines Type
Manual and Automatic Dispenser Compatible

Features
UV Resistant, Moisture Resistant, Impact Resistant

Material Grade
Industrial Grade

Diameter
Inner Core 76 mm

Thickness
0.8 mm

Purity
High Purity Acrylic

Application
Automotive, Construction, Electronics, Signage

Load Capacity
Up to 20 kg per meter

Form
Tape Roll

Color
Black

Product Type
VHB Tape

Main Material
Acrylic Foam

Surface Treatment
Adhesive Coated

Size
19 mm x 33 m

Weight
Approx. 400 g (per roll)

Feature
HIGH STRENGTH

Shape
Roll

Conformability
Excellent

Minimum Application Temperature
+15C

Adhesion to Steel
26 N/cm

Elongation at Break
400%

Temperature Resistance
-30C to 150C

Liner Material
Red Polyethylene

Waterproof
Yes

Initial Tack
High

Storage Condition
Store in a cool, dry place away from sunlight

Shelf Life
24 Months

Adhesive Type
Pressure Sensitive Acrylic

3M-B23F-VHB Black Tape Trade Information

Minimum Order Quantity
1 Roll

Delivery Time
4 Days

About 3M-B23F-VHB Black Tape

Dream, Design, Deliver with 3M VHB Structural Glazing Tape B23F. It is a black, 0.090 in. (2.3 mm), multi-purpose acrylic adhesive with a conformable foam core and film liner. It is commonly used for structural glazing. The fast and easy to use permanent bonding method provides high strength and long-term durability.

Convenience Meets Extreme Bonding Power
Our 3M VHB Tape consists of a durable acrylic adhesive with viscoelastic properties. This provides an extraordinarily strong double sided foam tape that adheres to a range of substrates, including aluminum, painted aluminum and glass. Our bonding tapes provide excellent strength, conformability, surface adhesion and temperature resistance. The 3M VHB Structural Glazing Tape family is used to attach glass panels to metal frames in curtain wall systems, commercial windows and doors, skylight and canopy systems replacing commonly used mechanical fasteners, gaskets and structural silicone sealants.

Recommended Application

Attach glass panels to metal frames (structural glazing)

Dream, Design, Deliver with the 3M VHB Structural Glazing Tape Family
3M VHB Structural Glazing Tapes utilize multi-purpose acrylic adhesive on both sides of a conformable, foam core. They are specifically designed for good adhesion to aluminum, painted aluminum, glass and other medium to high surface energy materials. Applications for these tapes include glazing and as an alternative to structural silicone and spacer tapes/gaskets.

Exceptional Bonding for Demanding Applications

Experience superior performance with the 3M-B23F-VHB Black Tape, engineered for high-strength demands in automotive, construction, electronics, and signage industries. Its advanced acrylic adhesive ensures firm, durable bonds that withstand harsh environments, including moisture, UV exposure, and temperatures from -30C to 150C. Trust this tape for reliable, permanent fixation and gap filling.

Designed for Easy Application and Versatility

This tape roll features a user-friendly peel-and-stick installation and excels in both manual and automatic dispenser systems. Its high conformability allows it to adhere smoothly to irregular surfaces, making it suitable for a variety of shapes and materials. The red polyethylene liner ensures quick, mess-free application every time.

FAQ's of 3M-B23F-VHB Black Tape:

Q: How do I apply the 3M-B23F-VHB Black Tape for optimal adhesion?

A: Ensure surfaces are clean, dry, and free from oils or dust before application. Peel off the red polyethylene liner, then firmly press the tape onto the desired surface, applying even pressure. For best results, apply at temperatures above +15C.

Q: What are the primary benefits of using this tape in industrial settings?

A: This tape offers high-strength bonding, excellent conformability, and resistance to moisture, UV, and temperature extremes. Its reliability for permanent fixation and gap filling make it ideal for demanding industrial applications.

Q: Where can I use the 3M-B23F-VHB Black Tape?

A: The tape is suitable for automotive assembly, construction projects, electronics manufacturing, and signage installations. Its high strength and environmental resistance make it versatile for both indoor and outdoor use.

Q: What is the shelf life, and how should I store the tape?

A: The shelf life is 24 months. To maintain performance, store the tape in a cool, dry place away from direct sunlight and extreme temperatures.

Q: What makes this tape suitable for heavy-load applications?

A: With a load capacity of up to 20 kg per meter and adhesion of 26 N/cm to steel, the tape delivers reliable, lasting support for demanding tasks, while also absorbing impact and filling gaps effectively.

Q: Can I use the tape on irregular or curved surfaces?

A: Yes, the tape's excellent conformability allows it to bond smoothly to curved or uneven surfaces without losing adhesion strength.

Q: Is the 3M-B23F-VHB Black Tape waterproof and UV resistant?

A: Yes, the tape is waterproof and resistant to UV exposure, making it suitable for outdoor applications where durability against weather is required.
